GIGABYTE B760I AORUS PRO DDR4 / Intel B760 / LGA1700 / 2x DDR4 / 2x M.2 / DP / HDMI / USB-C / WiFi / Mini-ITX

GIGABYTE B760I AORUS PRO DDR4 / Intel B760 / LGA1700 / 2x DDR4 / 2x M.2 / DP / HDMI / USB-C / WiFi / Mini-ITX

218,57 €

SKU: MotherboardsGIGABYTE-B760I-AORUS-1700 Category: Tag:

Description

GIGABYTE B760I AORUS PRO DDR4

The board is equipped with graphics outputs for use with processors with integrated graphics core. The motherboard does not include a graphics card and without the use of a corresponding processor, these outputs will be inoperative.

CPU

Support for 12th and 13th generation Intel Core/ Pentium/ Celeron processors (LGA1700 socket)

Chipset

Intel B760

Memory

2x DDR4 memory slots, support up to 64 GB

Support DDR4 5333 (OC)/ 5133 (OC)/ 5000 (OC)/ 4933 (OC)/ 4800 (OC)/ 4700 (OC)/ 4600 (OC)/ 4500 (OC)/ 4400 (OC)/ 4300 (OC)/ 4266 (OC)/ 4133 (OC)/ 4000 (OC)/ 3866 (OC)/ 3800 (OC)/ 3733 (OC)/ 3666 (OC)/ 3600 (OC)/ 3466 (OC)/ 3400 (OC)/ 3333 (OC)/ 3300 (OC)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MHz

Dual-channel memory architecture

ECC support, 1Rx8/2Rx8, unbuffered (non-ECC mode)

Support non-ECC, 1Rx8/2Rx8/1Rx16, unbuffered

Intel Extreme Memory Profile (XMP) support

Slots

Intel CPU

1x PCIe 4.0 x16 slot

Graphic arts

1x HDMI port, supporting max. resolution 4096 x 2160 at 60 Hz

1x DisplayPort port, supporting max. resolution 4096 x 2304 at 60 Hz

Storage

Intel CPU

1x M.2 slot, M Key, for type 2280 units (PCIe 4.0 x4/x2 mode)

Intel B760 chipset

1x M.2 slot, M Key, for type 2280 units (PCIe 4.0 x4/x2 mode)

4x SATA 6Gb/s ports

RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA drives

USB

1x USB 3.2 Gen2 Type-C port on the back panel

1x USB 3.2 Gen2 type A port on the back panel

6x USB 3.2 Gen1 (USB 3.0) ports (4 ports on the back panel, 2 ports available via internal USB connector)

1x USB 3.2 Gen1 (USB 3.0) Type C port available via internal USB connector

4x USB 2.0 ports (2 ports on the back panel, 2 ports available via internal USB connectors)

Audio

Realtek Audio Codec

2/4/5.1/7.1 channel High Definition Audio

S/PDIF output support

HIND

1x Intel 2.5Gigabit LAN controller

WLAN/Bluetooth

Intel Killer Wi-Fi 6 AX1650

Wi-Fi 802.11a/b/g/n/ac/ax

Dual Band (2.4GHz, 5GHz)

Bluetooth 5.2

Internal connectors

1x 24-pin ATX main power connector

1x 8-pin ATX 12V power connector

1x CPU fan connector

1x CPU fan/water cooling pump connector

1x system fan connector

1x addressable LED strip connector

1x RGB LED strip connector

2x M.2 slots, M Key

4x SATA 6 Gb/s connector

1x front panel connector

1x front panel audio connector

1x speaker connector

1x USB 3.2 Gen1 (USB 3.0) type C connector

1x USB 3.2 Gen1 (USB 3.0) connector (supports 2x USB 3.2 Gen1 port)

1x USB 2.0 connector (supports 2x USB 2.0 port)

1x Reset jumper

1x Clear CMOS jumper

1x case opening detection connector

Rear panel ports

1x USB 3.2 Gen2 Type-C

1x USB 3.2 Gen2 type A

4x USB 3.2 Gen1 (USB 3.0)

2x USB 2.0

1x DisplayPort

1x HDMI

1x Q-Flash Plus button

1x RJ-45

2x Wi-Fi antenna connector

1x optical S/PDIF output

2x audio jacks

/>

Dimensions

17 x 17 cm

Mini ITX format

Additional information

Brand

GIGABYTE
Model

GIGABYTE
Warranty period for registration number (months)

36
Manufacturer

GIGABYTE
Warranty length (months)

36
Processed

Approved
Wi-Fi

Yes
RJ-45 (number)

1
Dimensions

170 × 170 mm
USB 2.0 (number)

2
Gigabit LAN

Yes
Wi-Fi standard

802.11a/b/g/n/ac/ax
USB Type C (number)

1
USB 3.0 (number)

4
Analog audio input/output (number)

2
HDMI (number)

1
TDP (W)

150
USB 3.1 (number)

1
RAM type

DDR4
Chipset

Intel B760
Number of memory slots

2
DisplayPort (number)

1
Motherboard format

Mini-ITX
PCI Express X16 (number)

1
RAID controller

Yes
Processor socket

1700
M.2 port (for expansion cards)

No
SATA III (number)

4
M.2 port (number)

2
Optical audio output (number)

1
SPDIF optical (number)

1
