ASUS TUF GAMING B760-PLUS WIFI D4 / Intel B760 / LGA1700 / 4x DDR4 / 3x M.2 / DP / HDMI / 1x USB-C / WIFI / ATX

Description

ASUS TUF GAMING B760-PLUS WIFI D4

The board is equipped with graphics outputs for use with processors with integrated graphics core. The motherboard does not include a graphics card and without the use of a corresponding processor, these outputs will be inoperative.

CPU

Support for 12th and 13th generation Intel Core/ Pentium/ Celeron processors (LGA1700 socket)

Chipset

Intel B760

Memory

4× DDR4 memory slots, support up to 128 GB

Support DDR4 5333 (OC)/ 5066 (OC)/ 5000 (OC)/ 4800 (OC)/ 4600 (OC)/ 4400 (OC)/ 4266 (OC)/ 4000 (OC)/ 3733 (OC)/ 3600 (OC)/ 3466 (OC)/ 3400 (OC)/ 3333 (OC)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz

Dual-channel memory architecture

Support non-ECC, unbuffered memory

Intel Extreme Memory Profile (XMP) support

OptiMem II support

Slots

Intel CPU

1× PCIe 5.0 x16 slot

Intel B760 chipset

1× PCIe 3.0 x16 slot (supports x4 mode)

2× PCIe 3.0 x1 slots

Graphic arts

1× HDMI port, supporting max. resolution 4K at 60 Hz

1× DisplayPort port, supporting max. resolution 4K at 60 Hz

Storage

Intel CPU

1× M.2 slot, M Key, for 2242/2260/2280 type units (PCIe 4.0 x4 mode)

Intel B760 chipset

1× M.2 slot, M Key, for units of type 2242/2260/2280/22110 (PCIe 4.0 x4 mode)

1× M.2 slot, M Key, for 2242/2260/2280 type units (PCIe 4.0 x4 mode)

4× SATA 6Gb/s ports

RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA drives

Intel Rapid Storage technology support

USB

1× USB-C 3.2 Gen2x2 port on the back panel

1× USB 3.2 Gen2 port on the back panel

1× USB-C 3.2 Gen2 port available via internal USB connector

5× USB 3.2 Gen1 (USB 3.0) ports (3 ports on the back panel, 2 ports available via internal USB connector)

5× USB 2.0 ports (1 port on the back panel, 4 ports available via internal USB connectors)

Audio

Realtek Audio Codec

7.1 channel High Definition Audio

S/PDIF output support

HIND

1x Realtek 2.5Gigabit LAN controller

TUF LANGuard

WLAN/Bluetooth

Intel Wi-Fi 6

Wi-Fi 802.11a/b/g/n/ac/ax

Dual Band (2.4GHz, 5GHz)

Bluetooth 5.2

Internal connectors

1× 24pin main power connector

1× 8pin 12V power connector

1× 4pin 12V power connector

4× SATA 6Gb/s connector

3× M.2 slots, M Key

1× USB-C 3.2 Gen2 connector

1× USB 3.2 Gen1 (USB 3.0) connector (supports 2× USB 3.2 Gen1 ports)

2x USB 2.0 connector (supports 4x USB 2.0 port)

1× 4pin CPU fan connector

1× 4-pin optional CPU fan connector

1× 4pin water cooling pump connector

4× 4pin chassis fan connector

3× addressable RGB LED strip connector

1x Aura RGB LED strip connector

1× Clear CMOS connector

1× serial port connector

1× front panel audio connector

1× system panel connector (with chassis intrusion detection)

1× Thunderbolt connector

Rear panel ports

1× HDMI

1× DisplayPort

1× USB 3.2 Gen2x2 Type-C

1× USB 3.2 Gen2 Type A

3× USB 3.2 Gen1 (USB 3.0) type A

1× USB 2.0

1× RJ-45

2× Wi-Fi antenna connector

5× audio jacks

1× optical S/PDIF output

Dimensions

30.5 × 24.4 cm

ATX format
